The FTLD10CD3C transceivers are compliant with the InfiniBand Trade Association (IBTA) CXP Specification, IEEE 802.ba 100GBASE-SR10 and CPPI interfaces supporting 12 parallel, bi-directional data channels at rates from 1G/bs to 11Gb/s per channel. The 사설 바카라 transceiver is RoHS compliant as described in Application Note AN-2038. For details of our compliance standards, clickhere.
Parameter | FTLD10CD3C |
---|---|
Operating Distance | 300 m |
Data Transfer Rate | 100G |
Form Factor | 사설 바카라 |
Receiver | PIN |
High End 사설 바카라se Temperature (ºC) | 70 °C |
Transmitter | 12x VCSEL |
Connector | MPO (MTP24) |
Media Type | Par사설 바카라lel MMF |
Data Rate | 135.6 Gb/s |
Protocol | Gigabit Ethernet Fibre Channel InfiniBand PCIe |
Voltage Supply (V) | 3.3 V |
Diagnostics | Digit사설 바카라 |
Wavelength (nm) | 850nm Band |
